| 44 | 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|---|
| Stack | 519 | 536 | 552 | 569 | 590 | 610 | 643 |
| Reach | 356 | 359 | 364 | 370 | 378 | 386 | 392 |
| Head Tube Length | 110 | 125 | 140 | 155 | 175 | 195 | 230 |
| Head Tube Angle | 69.5 | 70.5 | 71 | 72 | 72.5 | 73 | 73 |
| BB Height | 273 | 273 | 273 | 274 | 274 | 275.5 | 275.5 |
| BB Drop | 77 | 77 | 77 | 76 | 76 | 74.5 | 74.5 |
| Trail | 81 | 74 | 71 | 64 | 61 | 58 | 58 |
| Fork Length, Full | 378 | 378 | 378 | 378 | 378 | 378 | 378 |
| Fork Rake/Offset | 47 | 47 | 47 | 47 | 47 | 47 | 47 |
| Front Center | 576 | 577 | 583 | 585 | 594 | 603 | 619 |
| Chainstay Length | 420 | 420 | 425 | 425 | 425 | 425 | 425 |
| Wheelbase | 984 | 984 | 995 | 998 | 1008 | 1017 | 1033 |
| Top Tube Length, Horizontal | 493 | 500 | 530 | 541 | 556 | 569 | 586 |
| Bike Standover Height | 715 | 739 | 761 | 781 | 801 | 821 | 852 |
| Seat Tube Length | 430 | 460 | 490 | 510 | 530 | 550 | 580 |
| Seat Tube Angle | 75.25 | 75.25 | 73.25 | 73.25 | 73.25 | 73.25 | 73.25 |
| Crank Length | 165mm | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Handlebar Width | 360mm | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
| Stem Length | 70mm | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
| Saddle Width | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
| Seatpost Length | 300mm | 300mm | 350mm | 350mm | 350mm | 350mm | 350mm |
